Maybe you've got an older car stereo system that you want to get more from. Or perhaps you've got an all-new setup that you want to get the maximum out of. In either case, Soundstreams MPQ-7B (7) bands of equalization that'll let you fine-tune your sound, along with independent master volume, subwoofer level, and fader controls that'll maintain your highs and lows in balance. The MPQ-7B features RCA inputs so that you can connect them to your aftermarket system. The RCA outputs ensure that your amplifiers will get a clean, powerful signal for maximum performance.
30V Bipolar Switching Power Supply
20dB Headroom Eliminated Signal Overload
2 Selectable Balanced RCA Inputs w/ Input gain
Front, Rear, & Subwoofer RCA Outputs
Seven Frequency Bands with +/- 18db Boost/Cut
40Hz, 100Hz, 275Hz, 700Hz, 2kHz, 5kHz, 14kHz
Independent Subwoofer Level Control
Selectable Low-Pass Filter: 32Hz, 64Hz, 125Hz
Input Selector Switch
Fader Control
Blue Backlit Control Knobs
S/N Ratio: 115dB
THD: 0.05%
Stereo Separation: 82dB
Frequency Response: 10Hz-15kHz
Max Output Voltage: 8V
